Class Log¶

Fri 29 Oct 2021¶

In class we considered the numerical error accumulation in a chaotic system by evolving forward and backward in time. This gives something related to the Loschmidt echo.

Fri 24 Sept 2021¶

Plan:

Tell students to use a generated CC number (CITI has one) so they can use the shared runners on GitLab. (I tried it with a $1 limit and it was fine.)
Review error estimates, then start demonstrating Euler’s method. Maybe do this with the Lorenz system?
Discuss Stiff equations? Maybe construct an example.

%pylab inline --no-import-all
from scipy.integrate import solve_ivp

sigma = 10.0
beta = 8.0/3
rho = 28.0

q0 = (1.0, 1.0, 1.0)
t0 = 0.0

def fun(t, q):
   """Lorenz equations."""
   x, y, z = q
   return (sigma * (y-x), x * (rho - z) - y, x * y - beta * z)


T = 30.0
tols = [1e-3, 1e-5, 1e-8, 1e-12]
ress = [solve_ivp(fun, t_span=(0, T), y0=q0, atol=_tol, rtol=_tol/10,
                  dense_output=True)
        for _tol in tols]

fig, ax = plt.subplots()

res_best = ress[-1]
ts = res_best.t
qs = res_best.y

line_styles = ['-', '--', '-.']
for n, tol in enumerate(tols[:-1]):
    res = ress[n]
    err = abs(res.sol(ts) - qs).max(axis=0)
    l, = ax.semilogy(ts, err, ls=line_styles[n], label=f"tol={tol}")
    ax.axhline([tol], c=l.get_c(), ls=':')
ax.legend()
ax.set(xlabel='T', ylabel='max abs err');

%pylab is deprecated, use %matplotlib inline and import the required libraries.
Populating the interactive namespace from numpy and matplotlib

Wed 22 Sept 2021¶

We started working with the simple 1D problem posed on Monday, but stated without the solution.

\[ \dot{y}(t) = -ty(t), \qquad y(0) = 1. \]

%pylab inline --no-import-all
from scipy.integrate import solve_ivp

# Initial condition
y0 = 1.0

def fun(t, y):
    return -t*y

t0 = 0.0
tf = 3.0
res = solve_ivp(
    fun, t_span=(t0, tf),
    y0=[y0],  # Gotcha 1:
    t_eval=np.linspace(t0, tf, 100), # Gotcha 3:
    max_step=0.1,
)

fig, ax = plt.subplots()

ts = res.t
ys = res.y[0]  # Gotcha 2:

ax.plot(ts, ys)
ax.set(xlabel='t', ylabel='y');

%pylab is deprecated, use %matplotlib inline and import the required libraries.
Populating the interactive namespace from numpy and matplotlib

There are still a few “Gotcha”s here which need to be carefully addressed:

Reading the solve_ivp docs carefully, one sees that the parameter y0 has the following type:

y0 : array_like, shape (n,)

The following error is obtained:
```
>>> res = solve_ivp(fun, t_span=(t0, tf), y0=y0)
...
ValueError: `y0` must be 1-dimensional.
```
One needs to explain that floats are 0-dimensional, so we need to put the initial condition into a list or an array.
Similarly, in the results, res.y.shape == (1, Nt) because solve_ivp is setup to deal with a vector of parameters. Thus, we need to extract the zero-th element here. This was most easily explained in terms of the previous problem where x = res.y[0], y = res.y[1], etc.

This issue was typically encountered if students tried:
```
...
>>> ax.plot(res.t, res.y)
...
ValueError: x and y must have same first dimension, but have shapes (100,) and (1, 100)
```
The third “Gotcha” is that if you just use the default arguments, you get a very low-resolution plot (shown below). The reason is that the solver is adaptive, only evaluating the function where needed. To get more points, we need to either specify min_step or t_eval. I discussed both.

I mentioned a third option shown below of using dense_output=True, but did not show this in class:

res = solve_ivp(fun, t_span=(t0, tf), y0=[y0], dense_output=True)
plt.plot(res.t, res.y[0])

ts = np.linspace(t0, tf, 100)
plt.plot(ts, res.sol(ts)[0], ':', label='dense solution')
plt.gca().set(xlabel='t', ylabel='y');
plt.legend()

<matplotlib.legend.Legend at 0x7f5a31c30bb0>

We then solved the IVP and looked at the errors:

\[\begin{split} \int_{y_0}^{y} \frac{1}{y} \d{y} = \int_{t_0}^{t} -t\d{t}, \qquad \ln \frac{y}{y_0} = -\frac{t^2-t0^2}{2}\\ y(t) = y_0 e^{-(t^2-t_0^2)/2}. \end{split}\]

res = solve_ivp(fun, t_span=(t0, tf), y0=[y0], rtol=1e-5, atol=1e-5)

ts = res.t
ys = res.y[0]
ys_exact = y0 * np.exp(-(ts**2 - t0**2)/2)
abs_err = abs(ys_exact - ys)
rel_err = abs(abs_err/ys_exact)

fig, ax = plt.subplots()
ax.semilogy(ts, abs_err, label='abs_err')
ax.semilogy(ts, rel_err, label='rel_err')
ax.legend()
ax.set(xlabel='t', ylabel='err');

We then explored changing the tolerances a bit and discussed absolute vs. relative errors. I explained that if you scale your problem well, then these are roughly the same, but that usually the relative tolerance is more important (significant digits). However, when your solution is zero, your relative error will go through the roof, so you need to fallback on the absolute error.

Students asked why this plot looks so jumpy. I explained that if the solver is doing what it claims, then the solution will oscillate about the true solution within the specified errors, but that how it does this is up to the solver details.

Mon 20 Sept 2021¶

Today we worked on setting up ODE’s for use with solve_ivp. We started with the problem of solving for the motion of a projectile in a constant downward gravitational field, allowing for drag:

%pylab inline --no-import-all
from scipy.integrate import solve_ivp

m = 1.0        # Mass
g = 9.81       # Acceleration due to gravity
lam = 0.5      # Drag
h0 = 10.0      # Initial height
v0 = 10.0      # Initial velocity
theta = 45.0/180*np.pi  # Initial angle

# Initial condition
q0 = [
    0.0, 0.0, h0,  # x0, y0, z0
    v0*np.cos(theta), 0, v0*np.sin(theta),  # vx0, vy0, vz0
]

def fun(t, q):
    x, y, z, vx, vy, vz = q
    ax = -lam*vx / m
    ay = -lam*vy / m
    az = -lam*vz / m - g
    return [vx, vy, vz, ax, ay, az]

t0 = 0.0
tf = 3.0
res = solve_ivp(fun, t_span=(t0, tf), y0=q0, max_step=0.1)

fig, ax = plt.subplots()

ts = res.t
xs, ys, zs, vxs, vys, vzs = res.y
ax.plot(xs, zs)
ax.set(xlabel='x', ylabel='z', aspect=1);

%pylab is deprecated, use %matplotlib inline and import the required libraries.
Populating the interactive namespace from numpy and matplotlib

The following issues were encountered:

Some students were confused about how to write fun(t, q), especially about whether or not the initial conditions q0 should play a role. I discussed how fun(t, q) has access to q which allows you to forget about q0 etc. and focus on the current time. (However, there is the issue of m, g, etc. which maybe should be passed as default arguments?)

To try to simplify this, I suggested a simpler problem inspired by a known solution:

\[ y(t) = e^{-t^2/2}, \qquad \dot{y} = -te^{-t^2/2} = -ty(t), \qquad y(0) = 1. \]

This helped some students, but confused others because we switched gears mid-class. Here some students became fixated on the solution $e^{-t^2/2}$ and were not sure how this should enter their code. In future, just specify the IVP and then solve it later.

Wed 8 Sept 2021¶

Today we had the class fork the main repo so they could submit their work. The steps were:

Create a personal GitLab account.
Open private CoCalc account (in this case, created through the class course. Instructors like Matt Duez need to create a private account).

Open a terminal on CoCalc, and generate an ssh key if needed with ssh-keygen -t ed25519:

~$ ls ~/.ssh/              # See if keys exist
authorized_keys  known_hosts
$ ssh-keygen -t ed25519   # Generate new key if needed
Generating public/private ed25519 key pair.
Enter file in which to save the key (/home/user/.ssh/id_ed25519):
Enter passphrase (empty for no passphrase):
Enter same passphrase again:
Your identification has been saved in /home/user/.ssh/id_ed25519
Your public key has been saved in /home/user/.ssh/id_ed25519_1.pub
The key fingerprint is:
...
~$ ls ~/.ssh/              # Now keys exist
authorized_keys  id_ed25519  id_ed25519.pub  known_hosts

Start an ssh agent running bash and authenticate with ssh-add:

~$ ssh-agent bash
~$ ssh-add
Enter passphrase for /home/user/.ssh/id_ed25519:
Identity added: /home/user/.ssh/id_ed25519 (user@project-...)

Potential failure

Students may have created a key earlier but forgot their password. In this case, they should delete the keys and regenerate them:

~$ ssh-keygen -t ed25519
Generating public/private ed25519 key pair.
Enter file in which to save the key (/home/user/.ssh/id_ed25519):
/home/user/.ssh/id_ed25519 already exists.
Overwrite (y/n)? y
Enter passphrase (empty for no passphrase):
Enter same passphrase again:
Your identification has been saved in /home/user/.ssh/id_ed25519
Your public key has been saved in /home/user/.ssh/id_ed25519.pub
The key fingerprint is:
...

Copy the public key and add it to the student’s GitLab project (top right Preferences > SSH Keys).
```
~$ cat ~/.ssh/id_ed25519.pub
ssh-ed25519 AAAA...
```
Open the Official Course Repository on GitLab and create a Fork (top right) in the student’s personal namespace with Private visibility level. Have students alter the Project description so as to differentiate this from the Official Course Repository.
In this Fork, copy the Clone > Clone with SSH link i.e. git@gitlab.com:mforbes/physics-581-physics-inspired-computation.git.

Clone the private fork on CoCalc after first moving or removing any previously cloned repository:

~$ cd ~     # Go to home directory
~$ ls       # See if there are any previous clones
2021-09-08-131459.term  physics-581-physics-inspired-computation
~$ mv physics-581-physics-inspired-computation physics-581-physics-inspired-computation_old
~$ git clone git@gitlab.com:mforbes/physics-581-physics-inspired-computation.git
Cloning into 'physics-581-physics-inspired-computation'...
...

Potential failure

This needs to be done in the terminal where ssh-agent bash and ssh-add were run, otherwise the clone will fail:

~$ git clone git@gitlab.com:mforbes/physics-581-physics-inspired-computation.git
Cloning into 'physics-581-physics-inspired-computation'...
git@gitlab.com: Permission denied (publickey,keyboard-interactive).
fatal: Could not read from remote repository.

Please make sure you have the correct access rights
and the repository exists.

Perhaps we should add something like this to ~/.bash_aliases:

...
# if we can't find an agent, start one, and restart the script.
if [ -z "$SSH_AUTH_SOCK" ] ; then
  exec ssh-agent bash -c "ssh-add ; $0"
  exit
fi
...

This would ensure an agent is always running, requiring only ssh-add.

After cloning, the private fork should be the remote called origin. Add the Official Course Repository as a remote called upstream with git remote add upstream git@gitlab.com:wsu-courses/physics-581-physics-inspired-computation.git:

~$ cd ~/physics-581-physics-inspired-computation
~/physics-581-physics-inspired-computation$ git remote -v
origin  git@gitlab.com:mforbes/physics-581-physics-inspired-computation.git (fetch)
origin  git@gitlab.com:mforbes/physics-581-physics-inspired-computation.git (push)
~/physics-581-physics-inspired-computation$ git remote add upstream git@gitlab.com:wsu-courses/physics-581-physics-inspired-computation.git
~/physics-581-physics-inspired-computation$ git remote -v
origin  git@gitlab.com:mforbes/physics-581-physics-inspired-computation.git (fetch)
origin  git@gitlab.com:mforbes/physics-581-physics-inspired-computation.git (push)
upstream        git@gitlab.com:wsu-courses/physics-581-physics-inspired-computation.git (fetch)
upstream        git@gitlab.com:wsu-courses/physics-581-physics-inspired-computation.git (push)

Now students can git pull and git push to interact with their private repo, and git pull upstream main to get updates from the Official Course Repository.

Pull any changes from the Official Course Repository, and then run make init:
```
~/physics-581-physics-inspired-computation$ git pull upstream main
    $ git pull upstream main
From gitlab.com:wsu-courses/physics-581-physics-inspired-computation
 * branch            main       -> FETCH_HEAD
Already up to date.
~/physics-581-physics-inspired-computation$ make init
git clone git@gitlab.com:wsu-courses/physics-581-physics-inspired-computation_resources.git _ext/Resources
Cloning into '_ext/Resources'...
...
```
Crash and burn failure

Many students ran into a major issue where make init failed due to an error introduced into the laatest setuptools two days ago:
- [BUG] error in XXXX setup command: use_2to3 is invalid when false. #2775
To fix this for now, we pin the version of setuptools<58.0.2|>=59 in anaconda-project.yaml.
Once this is done, when a new terminal is started, it should be using the phys-581-2021 kernel:
```
(phys-581-2021) ~$
```
This kernel should also be available in Jupyter Notebooks in the list of Kernels.

(Incomplete) Specify the [Git] username and email so that students can commit by specifying the following in their CoCalc project **Settings > Custom environment variables (The LC_EDITOR need not be specified unless students prefer vi to the default nano.):

{
  "LC_GIT_USERNAME": "Michael McNeil Forbes",
  "LC_GIT_USEREMAIL": "m.forbes@wsu.edu",
  "LC_EDITOR": "vi",
}

The project needs to be restarted for these to take effect. After restarting, [Git] should see these:

~$ git

````{admonition} Potential failure
If this is not done properly, students may get an error like the following:

```console
(phys-581-2021) ~/physics-581-physics-inspired-computation$ git commit

*** Please tell me who you are.

Run

  git config --global user.email "you@example.com"
  git config --global user.name "Your Name"

to set your account's default identity.
Omit --global to set the identity only in this repository.

fatal: empty ident name (for <user@fa57a33d76fc>) not allowed

Our current ~/.bash_aliases file uses LC_GIT_USERNAME and LC_GIT_USERMAIL to set the following:

export GIT_AUTHOR_NAME="${LC_GIT_USERNAME}"
export GIT_AUTHOR_EMAIL="${LC_GIT_USEREMAIL}"
export GIT_COMMITTER_NAME="${LC_GIT_USERNAME}"
export GIT_COMMITTER_EMAIL="${LC_GIT_USEREMAIL}"

These should only be set if the variables are defined, otherwise, they will have empty values cause any customization in ~/.gitconfig to be ignored. This will be fixed in the next version of mmf_setup.
